L956F Part book Catelogue

SDLG L958F Loader2927002956.S1A:后车架附件-100 Accessories

item description part code qty
1 WASHER 4015000426 10
2 SCREW 4011001248 10
3 Plate 29270021461 1
4 BOLT 29250000291 5
5 SHIM 29250000301 15
6 SHIM 4043000374 4
7 Lubricating pipe 29270020201 1
8 Lubricating pipe 29270020221 1
9 RUBBER SLEEVE 29270009101 2
10 SCREW 4011001299 2
11 PIN 29270010071 1
12 SEALING RING 29270010081 2
13 RETAINING RING 4015000270 2
14 SPHERICAL PLAIN BEARING 4021000243 1
15 PLASTIC PLUG 29270009421 2
16 PIN 29270010881 1
17 BUSHING 29270010131 2
18 SEALING RING 4030000260 2
19 SCREW 4011001316 8
20 FLANGE 29270010181 1
21 SHIM 29270010161 1
22 SHIM 29270010151 2
23 SHIM 29270010171 1
24 ROLLER BEARING 4021000244 2
25 FLANGE 29270010141 1
26 NUT 4013000385 8
27 GROMMET 29270010891 1
28 SHIM 29270010241 1
29 SHIM 29270010251 1
30 SHIM 29270010231 1
31 SHIM 29270010221 1
32 FLANGE 29270010261 1
33 SCREW 4011001328 4
34 WASHER 4015000436 8
35 SCREW 4011001267 4
36 FOOT STEP 29270010821 1
37 PIN 29270010271 2
38 SCREW 4011001241 12
39 WASHER 4015000428 12
40 Cover plate 29270029581 1
41 Lubricating pipe 29270028951
42 ABSORBER 4190001829 2
43 LUBRICATING PIPE 29270014461 1
44 WASHER 4015000433 16
45 SCREW 4011001304 8
46 NUT 4013000370 8
47 Lubricating pipe 29270028971
48 BOLT 4011000220 4
49 NUT 4013000020 4
50 Cover plate 29270029591 1
51 SCREW 4014000510 2
52 SPRING WASHER 4015000035 2
53 CLAMP 29250000311 1
54 NIPPLE 29250014121 5
55 LUBRICATING NIPPLE 4030000065 6
56 FOOT STEP 29270010781 1

2943001024.S:驾驶室外置电气总成-96 Electric equipment

item part name description part code Qty
1 工作灯LED43-7410 Lamp 4130002839 4
2 组合开关86303 LIGHT SWITCH 4130001043 1
3 螺钉GB70.1-M525EpZn-8.8 SCREW 4014000249 2 4 启动开关 STARTER SWITCH 11217633 1 5 螺钉GB818-M516EpZn-4.8 SCREW 4014000088 4
6 垫圈GB97.1-5EpZn-300HV WASHER 4015000110 4
7 组合仪表盘PCAN-T32 Panel 29370019521 1
8 警示灯开关CVAB2AV0B-JSD Rocker switch 4130003050 1
9 过渡框CVA-01 Switch panel 4130003051 1
10 橡胶盖LGB348-32*5 Rubber plug 4043002740 1
11 前照灯开关CVAB2AJ0B-QZD Rocker switch 4130003048 1
12 后照灯开关CVAB2AJ0B-HZD Rocker switch 4130003047 1
13 刮雨器开关CJKB2BJ0B-GYQ Rocker switch 4130003046 1
14 喷水开关CVBB2AJ0B-PS Rocker switch 4130003045 1
15 盖板390-09002-001 Cover plate 4130003044 6
16 铲斗先导限位开关CVAB2AJ0B-CDXW Rocker switch 4130003043 1
17 动臂先导限位开关CVAB2AJ0B-DBXW Rocker switch 4130003042 1
18 侧边单框架536-11583-001 Switch panel 4130003041 6
19 动力切断开关CV4B2TYJB-DLQD Rocker switch 4130003075 1
20 中间单框架536-11582-001 Switch panel 4130003039 10
21 静音开关CVAB2AV0B-JY Rocker switch 4130003038 1

J2300-2923001136.S1A:驻车制动总成-96 Parking brake syetem

item part name description part code Qty
1 气室固定支架 Bracket 29230011381 1
2 螺栓GB16674.1-M1230flZnyc-8.8-480 Bolt 4011001375 4 3 驻车制动气室 LY50B2-3507002 SPRING BRAKE CHAMBER 4120005691 1

4 气压信号灯开关HFF-3757002 PRESSURE SWITCH 4130000055 1

5 垫圈 Washer 29220000171 1

6 螺栓JB999-M141.528EpZn-35 BOLT 4011000339 1

7 垫圈 Washer 29220000021 2

8 三通块 Nipple 29230000151 1

9 软管LGB145-202050 Hose assembly 4041002196 1

10 接头体 NIPPLE 29230000121 2

11 制动电磁阀LG23-DCFA BRAKE VALVE 4120003756 1

12 支架 Bracket 29230010861 1

13 螺栓GB16674.1-M820flZnyc-8.8-480 SCREW 4011001296 2
14 电磁阀进气管 HOSE ASSEMBLY 29230000131 1
15 垫圈 Washer 29220009121 3
16 螺栓 Bolt 29220009111 1
17 压力开关LY-3720002 PRESSURE SWITCH 4120000760 1
