LGMG AT40 2025 – Air filter assy – A1801-2718011273.S1B
Category: 2025 > AT40 > A0400W3M0A105
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6170-M10flZnyc-10-480 | 4013010346 | 4 |
| 2 | Air compressor air intake hose 35*5*200 | 27180112761 | 1 |
| 3 | Hose clamp JB8870-D40 | 4017000008 | 8 |
| 4 | Air compressor air intake pipe 25*1.5*492 | 27180112771 | 1 |
| 5 | Pipe | 27180110911 | 1 |
| 6 | Plate | 27030122151 | 1 |
| 7 | Rubber support | 27030122161 | 2 |
| 8 | Air intake pipe bracket 90*86*40 | 27180112752 | 1 |
| 9 | Bolt GB16674.1-M8*30flZnyc-8.8-480 | 4011011017 | 1 |
| 10 | Nut GB6177.1-M8flZnyc-8-480 | 4013010386 | 1 |
| 11 | Air filter subassy | 27180112802 | 1 |
| 12 | Bolt GB16674.1-M10*70flZnyc-8.8-480 | 4011011443 | 2 |
| 13 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 10 |
| 14 | Bolt GB16674.1-M10*30flZnyc-10.9-480 | 4011011594 | 2 |
| 15 | Bolt GB16674.1-M10*35flZnyc-8.8-480 | 4011011104 | 8 |
| 16 | Butterfly spring clamp φ184-φ206 | 4190708173 | 2 |
| 17 | Air outlet hose 192*7*1026 | 27180112791 | 1 |
| 18 | Vacuum level alarm | 4110001427 | 1 |
| 19 | Butterfly spring clamp φ133-φ156 | 4190708169 | 4 |
| 20 | Air outlet pipe 130*1.5*657 | 27180112851 | 1 |
| 21 | Pipe bracket 265*98*43 | 27180112741 | 1 |
| 22 | Pipe strap | 27180112781 | 1 |
| 23 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 2 |
