LGMG Mine Truck Mine Truck – Hydraulic oil tank assy – M1600-2716010697
Category: Mine Truck > Mine Truck > M0860WED0
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Oil charging breather bracket | 27160106261 | 1 |
| 2 | Liquid level gauge YWZ-127 | 4120000317 | 1 |
| 3 | Bolt GB16674.1-M6*16EpZn-8.8 | 4011000153 | 8 |
| 4 | Steering switch value spool | 27160105751 | 1 |
| 5 | O-ring GB3452.1-47.5*3.55G | 4030000130 | 2 |
| 6 | O-ring AS568-50.47*2.62 | 4120001417 | 2 |
| 7 | Elevation switch value spool | 27160105781 | 1 |
| 8 | Ring magnet LG03-CT58*20*13 | 4120000669 | 1 |
| 9 | Oil drain flange cover | 27160105801 | 1 |
| 10 | Hydraulic oil tank | 27160106981 | 1 |
| 11 | Oil return filter element SJXHL-250X*10 | 4120000304 | 1 |
| 12 | O-ring GB3452.1-128*3.55G | 4030000633 | 3 |
| 13 | Oil return flange assembly | 27160105531 | 1 |
| 14 | Bolt GB16674.1-M8*20EpZn-8.8 | 4011000458 | 18 |
| 15 | O-ring LGB168-11124 | 4041000767 | 2 |
| 16 | Nut LGB135-01422 | 4041000774 | 2 |
| 17 | Bolt GB16674.1-M8*16EpZn-8.8 | 4011000461 | 4 |
| 18 | Refueling filter respirator | 4120000303 | 1 |
