LGMG MT126H 2025 – Installation assembly 01 – J1101-2711011360.S1A
Category: 2025 > MT126H > C126HC3A0M009
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 4 |
| 2 | Air reservoir 30L（275）（LinGong grey） | 4120711728 | 1 |
| 3 | Hose clamp φ275-φ280（LinGong grey） | 4120711725 | 2 |
| 4 | Plug NG12-M22*1.5 | 4120000201 | 1 |
| 5 | Nut seat | 27110107601 | 2 |
| 6 | Drain valve | 4120000200 | 1 |
| 7 | Air cylinder bracket | 27110113241 | 1 |
| 8 | The air reair storage tank fixing bracket weldment | 27110114091 | 1 |
| 9 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 2 |
| 10 | Washer GB97.1-16EpZn-300HV | 4015000181 | 2 |
