Description
LGMG MTH116 2025 – Covering elec module – K2002-2720021349.S1A
Category: 2025 > MTH116 > C1160Y3A0A001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-4flZnyc-300HV-480 | 4015010290 | 8 |
| 2 | Nut GB6170-M4flZnyc-8-480 | 4013010304 | 8 |
| 3 | Side steering lamp 43-3001A | 4130000343 | 2 |
| 4 | LED FR work lamp SG-GZ050C | 4130704856 | 2 |
| 5 | SMG-011 Side marker lamp 3112040324 | 4130001148 | 2 |
| 6 | Elec horn DL125-100LW-01H | 4130712686 | 1 |
| 7 | Elec horn DL125-100LW-01L | 4130712685 | 1 |
| 8 | Bolt GB16674.1-M8*20flZnyc-8.8-480 | 4011010966 | 2 |
| 9 | Washer GB97.1-4EpZn-300HV | 4015000135 | 8 |
| 10 | Nut GB6177.1-M8flZnyc-8-480 | 4013010386 | 2 |
| 11 | Cmt series truck fog lamp harness | 27200208051 | 1 |
| 12 | Jacket | 27200154051 | 2 |
| 13 | Sheath LGB313-6*32 | 4043001111 | 6 |
| 14 | Low voltage cable bracket 80*35*20 | 27200155291 | 2 |
| 15 | Bolt GB16674.1-M10*25flZnyc-8.8-480 | 4011011015 | 1 |
| 16 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 2 |
| 17 | Nut GB6172.1-M4EpZn-05 | 4013000047 | 8 |
| 18 | Holder | 27200142321 | 1 |
| 19 | Bolt gb16674.1-m10*80flznyc-8.8-480 | 4011011904 | 1 |
| 20 | Lh walkway harness | 27200213521 | 1 |
| 21 | Rh walkway harness | 27200213511 | 1 |
| 22 | Outline marker light harness | 27200172391 | 2 |
| 23 | LED front fog light SM6053 (ordinary two-pin plug) | 4130712650 | 2 |
| 24 | Spotlamp work lamp WK-55HL（3312040131） | 4130001153 | 2 |
| 25 | Floodlamp work lamp WK-55HL（3312040210） | 4130001152 | 2 |
| 26 | Third generation turn signal DI-621 | 4130705210 | 2 |
| 27 | Screw GB818-M4*20flZnyc-4.8-480 | 4014010121 | 16 |
