LGMG Off-Highway Dump Truck 2020 – Oil bath air filter – A1800-2718010604
Category: 2020 > Off-Highway Dump Truck > MT86H > M086HWE82
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Oil bath mounting bracket Ⅱ | 4110703256 | 1 |
| 2 | Oil bath mounting bracket Ⅰ | 4110703255 | 1 |
| 3 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 12 |
| 4 | Washer GB97.1-12EpZn-300HV | 4015000168 | 20 |
| 5 | Bolt GB5782-M12*60EpZn-8.8 | 4011000260 | 4 |
| 6 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 2 |
| 7 | Base assembly | 27180106131 | 1 |
| 8 | Vacuum level alarm | 4110001427 | 1 |
| 9 | Wire | 27200107621 | 1 |
| 10 | Pipe | 27180106071 | 1 |
| 11 | High level intake assy | 4190704015 | 1 |
| 12 | Clamp 190 | 27180103511 | 1 |
| 13 | Pipe | 27180106081 | 1 |
| 14 | T-bolt clamp φ188-φ196 | 4190002630 | 3 |
| 15 | Block | 27180102272 | 1 |
| 16 | ASSEMBLY | 27180102682 | 1 |
| 17 | Washer GB96.1-10EpZn-300HV | 4015000197 | 6 |
| 18 | Exhaust pipe strap | 27240102331 | 1 |
| 19 | No longer used | 4019010001 | 3 |
| 20 | Pipe | 27180102181 | 1 |
| 21 | Pipe | 27180102831 | 1 |
| 22 | Oil bath air filter 3560 | 4190704013 | 1 |
| 23 | Hose clamp JB8870-D32 | 4017000011 | 2 |
| 24 | Protecting cover | 27180102281 | 1 |
| 25 | Inlet air steel pipe of engine | 27180103501 | 1 |
| 26 | Bolt GB5783-M8*40EpZn-8.8 | 4011000299 | 3 |
| 27 | Connecting pipe | 27180103491 | 1 |
| 28 | Bolt GB5782-M12*110EpZn-8.8 | 4011000262 | 8 |
| 29 | Bolt GB5782-M10*70EpZn-8.8 | 4011000051 | 2 |
| 30 | Support | 27180106091 | 1 |
| 31 | Rubber pad | 27180103521 | 1 |
| 32 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
| 33 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 10 |
| 34 | High level intake strap | 4110703257 | 1 |
| 35 | RUBBER PAD | 27180105601 | 1 |
| 36 | Oil bath air intake hose | 4190704016 | 1 |
| 37 | Bolt GB5783-M12*20EpZn-8.8 | 4011000087 | 8 |
| 38 | Washer GB96.1-12EpZn-300HV | 4015000186 | 12 |
