LGMG Off-Highway Dump Truck 2023 – ASM-bracket mounting – H1501-2715012501.S1A
Category: 2023 > Off-Highway Dump Truck > MT96LF > M096LW4A0M037
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB96.1-8flZnyc-300HV-480 | 4015010289 | 1 |
| 2 | Pipe clamp TTPG-215 | 4120704062 | 2 |
| 3 | Cover plate | 27410100861 | 1 |
| 4 | Bolt GB5783-M8*50flZnyc-8.8-480 | 4011010973 | 1 |
| 5 | Plate | 27150123082 | 1 |
| 6 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 1 |
| 7 | Clamp | 27150123572 | 2 |
| 8 | Cushion sleeve LGB123-0426 | 4041001484 | 1 |
| 9 | Washer GB97.1-12EpZn-300HV | 4015000168 | 1 |
| 10 | Nut GB6170-M12EpZn-8 | 4013000011 | 1 |
| 11 | Nut GB6170-M10EpZn-8 | 4013000007 | 1 |
| 12 | Washer GB97.1-10EpZn-300HV | 4015000162 | 1 |
| 13 | Bolt GB5782-M10*40EpZn-8.8 | 4011000504 | 1 |
| 14 | Nut GB6170-M8flznyc-8-480 | 4013010291 | 1 |
