LGMG ？？？a？2？？？？？？？°a？2？¨？？？| 2025 – Transmission shaft installation – F0901-2709010622.S1A
Category: 2025 > ？？？a？2？？？？？？？°a？2？¨？？？| > MS40HF > MS40HW4A0M010
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 4 |
| 2 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 2 |
| 3 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 4 | Transmission shaft assy | 4110000392 | 1 |
| 5 | FR transmission shaft LG09-QCDZ-1390 | 4110706049 | 1 |
| 6 | Transmission shaft assy | 4110001738 | 1 |
| 7 | Bolt GB5785-M14*1.5*55flZnyc-12.9-480 | 4011011613 | 12 |
| 8 | Nut GB6185.2-M14*1.5-12 | 4013010266 | 24 |
| 9 | Connecting seat weldment | 27090106201 | 1 |
| 10 | Bolt GB5786-M14*1.5*45-12.9 | 4011010607 | 4 |
| 11 | Washer GB96.1-14flZnyc-300HV-480 | 4015010371 | 4 |
| 12 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 4 |
